Products in hazardous areas - ATEX

Trace Heating system in EXplosion proof locationImage



ELTRACE SAS is ATEX certified (SIRA 09 ATEX M430)

ELTRACE Group, your trace heating partner, received the QAN (Quality Assurance Notification) for his complete range of trace heating cable.

ELTRACE provides a complete range of heating cable under the European recommandation for flameproof application (94/9/EC)

Being an ATEX-certified company, ELTRACE SAS fulfils the increased security standards according to the latest Ex-guidelines 94/9/EC.

Our project engineers will help you with the layout and the calculation of your electrical heat tracing system.



Do not hesitate to contact us for further information :

ELTRACE SAS

56, bld de Courcerin

F-77183 Croissy-Beaubourg

Tel: +33 1 64 62 04 40

Fax: +33 1 64 62 00 54

www.eltrace.com

Our product range in hazardous area

Self limiting cable and heating tapes

Mineral Insulated cable

Constant power cable

Controler


HEATING BELT - ELBH

HEATING BELT ELBH Image

AN ECONOMICAL SOLUTION TO DRUM HEATING PROBLEMS



Through its design (resisting wires embedded under silicone), the ELBH heating belt offers extraordinary flexibility in use.  A thermostat built into the belt prevents any risk of overheating



The dimensions of the ELBH heating belts cover most standard drums.

In addition, thanks to its spring attaching system, installation is also possible on specific drum diameters.





Read more...

Self Limiting Heating Cable - TRACECO

SELF-REGULATING HEATING TAPE

TRACECO® Image

A RELIABLE SOLUTION TO ALL YOUR PROBLEMS OF PROTECTION AGAINST ICE AND MAINTAINING DOMESTIC HOT WATER TEMPERATURE

The TRACECO line, of self-regulating heating tapes is used for protection of pipes and gutters against freezing, and for maintaining the temperature of domestic hot water networks.
Advantages: Cut to length on site.  Storage in rolls. Variable power preventing any overheating. Availability in stock. Can be used with the "DOMOCLICK" fast connec-tion system. U.V. protected with Santoprene® over jacket
ATEX
CSTB

Recommend this article...

Read more...

Self regulating heating tapes - TRACECO-15

SELF REGULATING TAPES

TRACECO-15®Image

THE SOLUTION TO FROST PROTECTION OF YOUR WATER AND LOW TEMPERATURE PRODUCT LINES



Applications: Frost protection, Low temperature maintenance, For pipes, gutters and storage tanks.

Advantages: Cut to length on site, storage in rolls, Variable power preventing overheating, Availability in stock, Can be used only with ELKSR-1 termination kit.ImageImage

Recommend this article...

Read more...

More...

Login






Lost Password?
No account yet? Register



Career and Employment

Postulez en ligne

Flash info

Round self-limiting cable 40w/m @ 0°C



THE UNIVERSAL SOLUTION FO YOUR PROBLEMS OF PROTECTING COLD ROOM SLIDING DOORS FROM FREEZING UP

Technical features:

ESR-Round-40
Maximum surface temperatur 55°C.
Supply voltage: 230 V.
Power
  • 40 W/m @ 0°C.
  • 50 W/m @ –20°C.
Maximum length circuit: 125m
Weight: 41.5g/m

Conductor :

Stranded nickelled copper 7 x 0.32mm
Diameter 1.43mm
Section 0.57mm²

Extrusion :

semi conductive compound
Dimensions : 4.10mm x 4.40mm

Insulation

White thermoplastic polymer
Radial thickness  0.85mm
Thickness  5.6mm +/- 0.4mm
Width 6.1mm +/- 0.4mm
